Explore the capabilities of the Intel Pentium Gold G6405 Coffee Lake Processor on our site. Find out how this processor can enhance your computing experience.
Specification
| Basic Information | ||
| Base Frequency | 4.10 GHz | |
| Cache | 4 MB Intel Smart Cache | |
| Cores | 2 | |
| Threads | 4 | |
| Default TDP | 58 W | |
| Memory Specifications | ||
| Maximum Size | 128 GB | |
| Maximum Speed | 41.6 GB/s | |
| Type | DDR4-2666 | |
| Max Number of Channels | 2 | |
| Graphics Specifications | ||
| Processor Graphics | Intel UHD Graphics 610 | |
| Base Frequency | 350 MHz | |
| Max Dynamic Frequency | 1.05 GHz | |
| Max Video Memory | 64 GB | |
| Max Resolution | Max Resolution (HDMI): 4096×2160@30Hz Max Resolution (DP): 4096×2304@60Hz Max Resolution (eDP – Integrated Flat Panel): 4096×2304@60Hz |
|
| Warranty Information | ||
| Manufacturing Warranty | 03 Years (No Warranty for Fan or Cooler) | |
Description
Intel Pentium Gold G6405 Coffee Lake Processor
The Intel Pentium Gold G6405 Coffee Lake Processor comes with 4M Cache, 4.10 GHz Processor Base Frequency. This Intel Pentium Gold G6405 processor comes with a new breed that has an integrated Intel UHD Graphics 610, so a separate graphics card is not required for its functionality. This new Comet Lake microarchitecture is manufactured with the 14nm process (Lithography) that comes with 2 cores and HyperThreading. As this chip is updated to the latest BIOS revision, it nicely fits into any Intel 300-series motherboard. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 300-series lineup Additionally, this Intel Pentium Gold G6405 processor also supports dual-channel 2666 MHz DDR4 memory and utilizes 10th-generation Intel technology.
Core Benefits of the Processor
Intel Pentium Gold G6405 Coffee Lake Processor comes with the base frequency of 4.10 GHz. It has the 4MB Intel Smart Cache containing 2 cores and 4 threads. With the bus speed of 8 GT/s DMI, it has thermal design power (TDP) rating of 58 W. This latest processor has few expansion options such 3.0 PCI express revision having configured up to Up to 1×16, 2×8, 1×8+2×4 and maximum 16 PCI Express Lanes. Considering the memory this processor has dual channel of max 128 GB Max Memory Size (dependent on memory type) that supports up to DDR4-2666 bus speed.
Advanced Facilities
This Pentium Gold G6405 processor comes with 2.0 Intel turbo boost and I/O (VT-d) Intel Virtualization Technology for Directed on the process of advanced technology. This Optane Memory supported chip also has Intel VT-x with extended page tables (EPT). Furthermore, Enhanced Intel SpeedStep and Intel Identity Protection Technology are integrated to increase its efficiency.
The Pentium Gold G6405 comes with integrated Intel UHD 610 graphics, which supports up to three displays with a maximum resolution of 4096 x 2304 at 60Hz with supported motherboards. The latest Intel Pentium Gold G6405 Coffee Lake Processor has 03 Years (No Warranty for Fan or Cooler).
